29354
29354
OrderableWi-Fi Kit for ET Stations
Overview
Intended for our ET107 stations, the 29354 is a wireless networking peripheral that provides Wi-Fi connectivity over standard 802.11b/g/n networks. It is a low-power device that offers unique and powerful PakBus networking capabilities, but it is easy to configure.
The 29354 includes a wireless network link interface.
Key Advantages
Technical Description
The 29354 can take advantage of the thousands of Wi-Fi hotspots available in cafés, universities, hotels, and airports. Wi-Fi also provides encryption to protect traffic and uses a global set of standards so the same device can be used internationally.
The 29354 is an industrial Wi-Fi kit that goes beyond the typical Wi-Fi serial device server. It supports Wi-Fi communication with an iOS or Android device when used with our LoggerLink apps. The 29354 provides:
- M2M communication of data and events
- PakBus communication over TCP/IP for remote configuration, control, and data collection
- HTTP and FTP for posting, retrieving, and local hosting of data
- Email client for data and control messaging
- ModBus TCP/IP, DNP3, and NTCIP ESS industrial protocol support
Benefits
- Low power consumption
- Can be configured to bridge Ethernet and CS I/O communications
- Has CS I/O, RS-232, and USB ports
Specifications
- Compliance
- CE Compliant
- Material
- Aluminum case with black anodized finish
- Configuration
- Device Configuration Utility over USB or Wi-Fi
- Configuration
- Terminal menu over Telnet
- Configuration
- Terminal menu over RS-232
- CS I/O Port
- SDC 7, 8, 10, or 11
(Does not support ME.)
- RS-232 Port
- DTE, DB9 Male
- USB Port
- Micro-B
- Operating Temperature Range
- -25° to +50°C
(standard)
- Connections/Routes Supported
- Supports 20 simultaneous TCP connections.
- Connections/Routes Supported
- Up to 10 of the 20 TCP connections can be used for TLS.
- Connections/Routes Supported
- PakBus Router supports 50 routes.
- Connections/Routes Supported
- 15 Modbus server transactions
(maximum)
- Dimensions
- 16 x 6.73 x 2.54 cm
(6.3 x 2.65 x 1 in.)
- Weight
- 177 g
(6.3 oz)
Communication Rate
- RS-232 Port
- 1200 to 115.2k bps
- CS I/O Port
- 9600 to 460.8k bps
WLAN
- Antenna Connector
- RPSMA
- Supported Technologies
- 802.11b/g/n, WPA, WPA2 /TKIP or AES, WEP, WEP(open), APIPA/AutoIP, IPv4, IPv6, ICMP/Ping, ICMPv6/Ping, TCP, DHCP Client, SLAAC, DNS Client, HTTPS Proxy, Telnet Server, TLS, PakBus, Modbus, TCP/IP
- Topologies
- Infrastructure and ad-hoc
- Transmit Power
- 7 to 17 dBm
(5 to 50 mW)
- Rx Sensitivity
- -97 dBm
(< 8% PER)
- Frequency
- 2.4 to 2.5 GHz
(2.4 GHz ISM band)
Power
- Power Connector
- CS I/O Port
(not powered over USB)
- Supply Voltage
- 7 to 20 Vdc
Power Consumption
- Maximum
- 950 mW
- Typical (Always On)
- 600 mW
(idle)
- Typical (Always On)
- 670 mW
(communicating)
- Typical (Always On)
- 65 mW
(searching for out-of-range network)
- Typical (Low Power Mode Enabled)
- 73 mW
(idle)
- Typical (Low Power Mode Enabled)
- 480 mW
(communicating)
- Typical (Low Power Mode Enabled)
- 50 mW
(searching for out-of-range network)
- Sleep
- 16 mW
