024A-L

Wind Direction Sensor
Hoa Pham

024A-L

RetiredConfigurable

Wind Direction Sensor

Pricing

Sign in for pricing

Configuration

Sign in for option pricing

Select a configuration to add to your quote

Model:
024A-L
Item Number:
2011
Warranty:
1 year
Lead time:
14 days

Overview

024A-L Met One Wind Direction Sensor

The 024A, manufactured by Met One, is a wind vane that measures wind direction only. You can use it in tandem with the 014A Wind Speed Sensor; however, this combination has been largely replaced by the 034B, which monitors both wind speed and wind direction.

Key Advantages

Reliable, Accurate Wind Direction
Compatible with most Campbell Scientific data loggers

Technical Description

The 024A Wind Vane measures wind direction from 0 to 360 degrees with a 5 degree accuracy specification. Wind direction is sensed with a 10 kohm potentiometer. With the precision excitation voltage from the data logger applied to the potentiometer element, the output signal is an analog voltage that is directly proportional to the azimuth of the wind direction.

Specifications

Sensor
Vane
Measurement Description
Wind direction
Operating Range
0 to 360°
Threshold
0.45 m s-1

(1.0 mph)

Accuracy
±5°
Operating Temperature Range
-50° to +70°C

(assumes non-riming conditions)

Delay Distance
< 1.5 m

(5 ft)

Damping Ratio
0.25

(standard)

Damping Ratio
0.4

(optional fast response)

Resolution
0.5°
Height
33.8 cm

(13.3 in.)

Length
44.7 cm

(17.6 in.)

Vane Height
30.5 cm

(12 in.)

Vane Width
7.6 cm

(3 in.)

Weight
450 g

(1 lb)

Potentiometer

Sand, Dust, and Fungus
MIL-E-5272
Salt Spray
MIL-E-12934
Resistance
0 to 10 kΩ
