LI7500
CO<sub>2</sub>/H<sub>2</sub>O Open-Path Gas Analyzer
LI7500
End of lifeConfigurableCO<sub>2</sub>/H<sub>2</sub>O Open-Path Gas Analyzer
Pricing
- Model:
- LI7500
- Item Number:
- LI7500
- Warranty:
- 1 year
- Lead time:
- 21 days
Overview
OBSOLETE LICOR LI7500 Open-Path C02/H20 Analyzer (13 Ft Lead)
On January 14, 2010, the LI7500 was replaced with the LI7500A. The LI7500A has been replaced with Campbell Scientific's EC150. Although retired, replacement parts remain available (see Ordering Info).
Specifications
- Type
- Absolute, open-path, nondispersive infrared gas analyzer
- Detector
- Thermoelectrically cooled lead selenide
- Bandwidth
- 5, 10, or 20 Hz, software selectable
- Operating Temperature Range
- -25° to +50°C
- Outputs
- RS-232
(20 Hz maximum)
- Outputs
- SDM
(> 40Hz)
- Power Requirements
- 10.5 to 30 Vdc
- Power Consumption
- 30 W
(during warm-up)
- Power Consumption
- 10 W
(in steady state)
- Path Length
- 12.5 cm
(4.72 in.)
- Head Diameter
- 6.5 cm
(2.6 in.)
- Head Length
- 30 cm
(11.8 in.)
- Control Box Dimensions
- 35 x 30 x 15 cm
(13.8 x 11.8 x 5.9 in.)
- Head Weight
- 0.75 kg
(1.65 lb)
- Control Box and Cables Weight
- 4.8 kg
(10.5 lb)
