CSAT3BCBL3
CPI/RS-485 Cable for CSAT3B
CSAT3BCBL3
OrderableConfigurableGSACPI/RS-485 Cable for CSAT3B
Pricing
Configuration
Sign in for option pricing- w/Ferrules on Wires w/3m (10ft) per CableCSAT3BCBL3-PF-3m
- w/RJ45 Connector w/3m (10ft) per CableCSAT3BCBL3-RJ-3m
- w/Ferrules on Wires w/5m (17ft) per CableCSAT3BCBL3-PF-5m
- w/RJ45 Connector w/5m (17ft) per CableCSAT3BCBL3-RJ-5m
- w/Ferrules on Wires w/10m (33ft) per CableCSAT3BCBL3-PF-10m
- w/RJ45 Connector w/10m (33ft) per CableCSAT3BCBL3-RJ-10m
- w/Ferrules on Wires w/15m (50ft) per CableCSAT3BCBL3-PF-15m
- w/RJ45 Connector w/15m (50ft) per CableCSAT3BCBL3-RJ-15m
- w/30m (99ft) per Cable w/Ferrules on WiresCSAT3BCBL3-PF-30m
- w/30m (99ft) per Cable w/RJ ConnectorCSAT3BCBL3-RJ-30m
- w/50m (165ft) per Cable w/Ferrules on WiresCSAT3BCBL3-PF-50m
- w/50m (165ft) per Cable w/RJ ConnectorCSAT3BCBL3-RJ-50m
- w/Ferrules on Wires w/60m (200ft) per CableCSAT3BCBL3-PF-60m
- w/RJ45 Connector w/60m (200ft) per CableCSAT3BCBL3-RJ-60m
Select a configuration to add to your quote
- Model:
- CSAT3BCBL3
- Item Number:
- 45164
- Warranty:
- 1 year
- Lead time:
- 14 days
Overview
CSAT3B CPI RS-485 Cable**
The CPI/RS-485 cable CSAT3BCBL3 is used to deliver CPI or CPI communications between a CSAT3B and a data logger, another CSAT3B, or a wiring hub.
Technical Description
One end of the cable always has a 6-pin M16 connector that mates with the CPI/RS-485 port on the back of the CSAT3B block. The other end of the cable has the following three options:
- The -PT option specifies the cable end to have pigtail wire leads for connecting to a PC (in the case of RS-485) or wiring hub.
- The -MC option specifies the cable end to have an M16 connector, which can be used to connect to a 30294 CPI/RS-485 Splitter, in the case of a CPI or RS-485 network of CSAT3B anemometers daisy-chained in series.
- The -RJ option specifies the cable end to have an RJ-45 connector, which can connect directly to the CPI port on a CPI-enabled data logger (such as the CR6) or to one of the ports on the HUB-CPI bus. The HUB-CPI bus is used for a CPI network of CSAT3B anemometers connected in parallel or in a star topology.
