HMP45C-QD
HMP45C-QD
End of lifeTemperature and Relative Humidity Probe for RAWS
Pricing
- Model:
- HMP45C-QD
- Item Number:
- 18765
- Warranty:
- 1 year
- Lead time:
- 21 days
Overview
The HMP45C-QD is a rugged, accurate temperature and relative humidity probe. The sensor measures relative humidity over the 0 to 100% RH range and temperature over the -40° to +60°C range.
Technical Description
For this version of the HMP45C Temperature and RH Probe, the cable has a military style connector instead of pigtails. The connector attaches to the RAWS-F Fire Weather Quick Deployment Station. The HMP45C-QD uses a HUMICAP capacitive polymer H chip to measure relative humidity over the 0 to 100% RH range. A PRT measures temperature over the -40° to +60°C range.
Benefits
- Well-suited for long-term, unattended applications
- Accurate and rugged
- Configured for use with the RAWS-F Fire Weather Quick Deployment Station
Specifications
- Supply Voltage
- 12 Vdc nominal
(typically powered by datalogger)
- Current Consumption
- ≤ 4 mA
(active)
Temperature
- Temperature Sensor
- 1000 ohm Platinum Resistance Thermometer
- Measurement Range
- -39.2° to +60°C
- Output Signal Range
- 0.008 to 1.0 V
- Accuracy
- See graph in HMP45C product brochure.
Relative Humidity
- Sensor
- Vaisala’s HUMICAP H-chip
- Measurement Range
- 0.8% to 100% RH
(non-condensing)
- Output Signal Range
- 0.008 to 1 Vdc
- Accuracy at 20°C
- ±1% RH
(against factory reference)
- Accuracy at 20°C
- ±2%
(0% to 90% range) field-calibrated against references
- Accuracy at 20°C
- ±3%
(90% to 100% range) field-calibrated against references
- Temperature Dependence
- ±0.05% RH/°C
- Long-Term Stability
- Typically, better than 1% RH per year
- Response Time
- 15 seconds with membrane filter
(at 20°C, 90% response)
- Settling Time
- 500 milliseconds
