CS505-L
Fuel Moisture Sensor
CS505-L
End of lifeConfigurableFuel Moisture Sensor
Pricing
- Model:
- CS505-L
- Item Number:
- CS505-L
- Warranty:
- 1 year
- Lead time:
- 21 days
- Compliance:
- requires 10824
Overview
The CS505 Fuel Moisture Sensor was retired on September 22, 2009. It consists of an epoxy-encapsulated electronics package. It uses Time Domain Reflectometry Technology to measure the moisture content of the 10824 10-hour Fuel Moisture Stick. The 10824 is a USFS-specified, 10-hour, ponderosa-pine dowel that is purchased as a Common Accessory (see Ordering Info).
Specifications
- Operating Range
- 0 to 70% moisture content
- Power Supply
- 9 to 18 Vdc
- Accuracy
- ±1% rms @ 0 to 10% moisture content
- Accuracy
- ±2.4% rms @ 30 to 40% moisture content
- Current Use
- 70 mA
(active)
- Current Use
- 10 µA
(quiescent)
- Output Signal
- ±2.5 Vdc square wave
(with an output frequency of 600 to 1500 Hz)
