End of lifeConfigurableHeated Rain Gage
Pricing
- Model:
- 385-L
- Item Number:
- 385-L
- Warranty:
- 1 year
- Lead time:
- 21 days
Overview
The 385 is an electrically heated rain gage that provides year-round measurement of rain or snow. It is a tipping-bucket rain gage widely used in environmental monitoring applications. The 385 funnels precipitation into a bucket mechanism that tips and actuates a switch. The momentary switch closure is counted by the pulse-counting circuitry of any of the Campbell Scientific data loggers. The gage is heated so that frozen precipitation melts and is measured right away as a liquid.
Technical Description
The 385 uses a 115-Vac blanket heater to provide year-round measurement of rain or snow. This sensor requires an adequately grounded, reliable ac power source.
The 385 measures in 0.01" increments and has a 12" diameter orifice. It funnels precipitation into a bucket mechanism that tips and activates a reed switch when filled to its calibrated level. The switch closure is recorded by the data logger. The 385 is compatible with all Campbell Scientific data loggers.
Before July 1994, the 385 used a cartridge heater. Met One will upgrade that cartridge heater to the blanket heater.
Benefits
- 300-W heating element melts snow and ice for year-round measuring
- High precision—tips at 0.01-in. increments
Specifications
- Sensor Type
- Tipping bucket with electric heater
- Accuracy
- ±0.5% @ < 1.25 cm (0.5 in.)/hr rate
- Accuracy
- ±2.0% @ < 7.50 cm (3.0 in.)/hr rate
- Resolution
- 0.254 mm (0.01 in.) per tip
- Heating Element
- 115 Vac (50/60 Hz) 300 W
- RH Operating Range
- 0 to 100%
Ships With
(1)- Calibration sheet
