30537
VWAnalyzer Cable with Unfinished End
30537
OrderableVWAnalyzer Cable with Unfinished End
Overview
ACC VWAnalyzer Cable w/Unfinished End, 5m (6.56ft)
The 30537 VWAnalyzer cable is an unfinished cable that allows users to add their own connector so that they can read their existing sensors with the VWAnalyzer. The unfinished cable should be attached to a user-supplied connector by the user.
Technical Description
The following cable color guide applies to the unfinished end of the 30537:
| Cable | Connector |
| Blue | Vibrating Wire Coil |
| Black | Vibrating Wire Coil |
| White | Thermistor/RTD Measurement |
| Brown | Thermistor/RTD Measurement |
| Grey | Ground/Shield |
| Pink | Unused |
Specifications
- Cable Length
- 2 m
(6.6 ft)
- Weight
- 58.97 g
(0.13 lb)
