108

Temperature Probe
Archive

108

OrderableConfigurable

Temperature Probe

Ideal for high-temperature environments.

Pricing

Sign in for pricing

Configuration

Sign in for option pricing

Select a configuration to add to your quote

Model:
108
Item Number:
45001
Warranty:
1 year
Lead time:
14 days
Compliance:
requires solar radiation shield for air temp

Overview

Temperature Sensor (-5 to +95C)

The 108 is a rugged, accurate probe that measures temperature of air, soil, or water from -5° to +95°C. It easily interfaces with most Campbell Scientific data loggers and can be used in a variety of applications.

The 108 consists of a thermistor encapsulated in an epoxy-filled aluminum housing. The housing protects the thermistor. allowing you to bury the probe in soil or submerge it in water.

Key Advantages

Rugged, Accurate, Versatile
Can be used in a variety of applications

Benefits

  • Versatile product—measures air, soil, or water temperature
  • Easy to install or remove
  • Durable
  • Compatible with AM16/32-series multiplexers, allowing measurement of multiple sensors

Specifications

Sensor Description
BetaTherm 100K6A1IA Thermistor
Tolerance
±0.2°C

(over 0° to 70°C range)

Temperature Measurement Range
-5° to +95°C
Steinhart-Hart Equation Error
≤ ±0.01°C over measurement range

(CRBasic data loggers only)

Polynomial Linearization Error
Typically < ±0.5°C over -5° to 90°C range

(Edlog data loggers only)

Time Constant in Air
30 to 60 s

(in a wind speed of 5 m s-1)

Maximum Submergence
15 m

(50 ft)

Maximum Cable Length
305 m

(1000 ft)

Probe Diameter
0.76 cm

(0.3 in.)

Probe Length
10.4 cm

(4.1 in.)

Weight
136 g

(5 oz) with 3.05 m (10 ft) cable
